Name: Technics SV-360
Brand: Technics
Price: 4.99 GBP
Availability: InStock

Description

The Technics SV-360 is a heavy duty professional DAT recorder dsigned for use in the recording studios.

Features the 4 DAC 18 bit system as found in the Technics' high end CD players.

XLR analogue connectors and coaxial digital connectors.

Identical to the Panasonic SV-3500.

Technical Specifications

Tape recording system	Rotating head type DAT
Sampling frequency (analog/digital input recording)	48 kHz
Sampling frequency (analog input recording)	44.1 kHz
Sampling frequency (digital input recording)	32 kHz
Sampling frequencies (playback)	48 kHz, 44.1 kHz, 32 kHz (selected automatically)
Quantization	16-bit linear
Number of channels	2 (stereo)
Frequency response (48 kHz)	10Hz~22,000 Hz (±0.5 dB)
Frequency response (32 kHz)	10Hz~15,000 Hz (±0.5 dB)
Dynamic range	90 dB or more
Dynamic range (playback)	96 dB or more
S/N ratio	93 dB or more
Total harmonic distortion	0.05% or less (1 kHz, input/output level +4 dBm)
Wow and flutter	Below limit of measurement
Analog input level	+4 dBs (-18 dB rec level)
Analog input impedance	10 kΩ
Analog output level	+4 dBm / -10 dBm (-18 dB)
Analog output impedance	20Ω / 135Ω
Headphone output	Max. 30 mW / 32Ω (matching impedance 8~600Ω)
Digital input	Coaxial 75Ω
Digital output	Coaxial 75Ω
Head type	Amorphous ferrite composite type
Cylinder diameter	30 mm
Cylinder rotation speed	2000 rpm (recording and playback)
Tape speed	8.15 mm/sec / 12.225 mm/sec (selected automatically)
Search speed	Max. 200 times normal speed
Fast forward winding time	Approx. 40 sec
Power supply	110V/127V/220V/240V AC, 50/60 Hz
Power consumption	40W
Dimensions	430(W) × 115(H) × 340(D) mm
Weight	7.5 kg
