Name: Teac DA-P20
Brand: Teac
Price: 4.99 GBP
Availability: InStock

Description

The Teac DA-P20 is identical to the Casio DA-7 except for the XLR input sockets and input pre-amplifier.

Features

Compact, lightweight, fully portable
Outstanding sound qualityDigital PCM recording and playback capabilities eliminate the noise, distortion, wow and flutter associated with analog system. This plus frequency characteristics and a dynamic range that are virtually incomparable with analog systems give you startlingly realistic fidelity.
Skip Play FunctionPress a button and instantly skip to the beginning of the selection you wish to hear.
Highly accurate time displaysA glance at the display shows you the elapsed time from the beginning of the tape (Absolute Time Display), the amount of time remaining on the tape (Remaining Time Display), and the amount of time for each selection (Program Time Display).
Microphone recordingA built-in microphone amplifier allows direct connection of microphones to the DA-P20.
Digital input/output JacksBuilt-in digital input/output jacks let you make digital recordings from compact discs, digital tape recorders, and other digital sources. The digital input/output jacks can be connected to the digital output jacks of another DAT unit for copying of digital codes.

Technical Specifications

Tape	DAT cassette tape
Tape speed	8.15 mm/sec (12.225 mm/sec in 1.5× playback mode with wide track)
Recording time	120 minutes continuous (with 120-minute tape)
Head	Rotary head
Drum speed	2,000 rpm (recording/playback)
Track pitch	13.6 µm (20.4 µm)
Sampling frequency (record)	48 kHz (44.1 kHz: digital input recording only)
Sampling frequency (playback)	48 kHz, 44.1 kHz
Quantization	16-bit linear
Modulation	8-10 modulation
Channels	2-channel stereo
Frequency response	20Hz~20 kHz (±1 dB)
Signal-to-noise ratio	Better than 90 dB
Dynamic range	85 dB
Total harmonic distortion	Less than 0.008% (at 1 kHz)
Wow and flutter	Unmeasurable (less than ±0.001%)
Emphasis	15/50 µS
Fast winding	70 seconds approx. (with R-120 cassette)
MIC/LINE input connector	XLR
Line input level (balanced)	-20 dBV (100 mV) / 10 kΩ
Line input level (balanced, PAD ON)	0 dBV (1V) / 10 kΩ
Line input level (unbalanced)	-13 dBV (224 mV) / 10 kΩ
MIC input level	-51 dBV (2.82 mV) / 10 kΩ
MIC input level (PAD ON)	-31 dBV (28.2 mV) / 10 kΩ
MIC input level (unbalanced)	-44 dBV (6.31 mV) / 10 kΩ
Line output connector	RCA
Line output level	-10 dBV (316 mV) / 1 kΩ
Headphone output connector	3.5mm mini-phone jack
Headphone output level	30 mW + 30 mW (32Ω)
Digital input connector	RCA (S/P DIF coaxial)
Digital output connector	RCA (S/P DIF coaxial)
Power supply	2-way — AC adaptor and Ni-Cd battery pack
Auto power off	Approximately 6 minutes after last operation
Power consumption	4.2W DC (2 hours playback/recording using battery pack recharged for approx. 8 hours)
Dimensions	243(W) × 158(D) × 45(H) mm
Weight	1.4 kg (including Ni-Cd battery pack)
Accessories	AC Adaptor PS-P20 (1), Rechargeable Battery Pack BP-P20 (1), RCA Cable (1), Carrying Belt (1)
